Swan Neck Conveyor

Available for hire

Available for sale

The Coveya Swan Neck Conveyor is a robust system designed to efficiently handle bulky, low-density materials in the waste and recycling industries. The Swan Neck Conveyor typically transfers material along a horizontal, flat section for a short period and then moves material quickly up at an inclined angle to discharge at height. They are typically used where space is restricted underneath machines such as shredders.

Length: Up to 30m

Belt Width: 1200mm, 600mm, 900mm

Max Throughput: 120 TPH

Enquire About Product Talk to an Expert

Information overview about product

The Swan Neck Conveyor is engineered to move bulky, low-density materials with ease, making it perfect for waste and recycling applications. Its efficient design allows for smooth and continuous material flow, even in spaces with height restrictions, such as underneath shredders.

Available in three widths (600mm, 900mm and 1200mm), the Swan Neck Conveyor can be easily customised to meet specific site requirements. Its modular design makes it the perfect solution for conveying materials out of areas where space is limited.

Constructed from high-quality materials, the Swan Neck Conveyor is built for durability and high performance. It offers belt speeds ranging from 0.3m/s to 0.9m/s and can handle a maximum throughput of 120 tons per hour. The conveyor can reach total lengths of up to 30 metres, with discharge heights of up to 6 metres thanks to its wide variety of incline angle options.

Available for purchase.
Designed for getting materials out of tight, restricted areas.
Wide variety of inclination angles available.

Additional information

Belt Speed	0.3 – 0.9m/p/s
Belt Width	1200mm, 600mm, 900mm
Length	Up to 30m
Loading Method	Excavator, Hand, Other conveyor, Small machine
Max Throughput	120 TPH
Mobile or Static	Mobile on Castors, Static
Power Supply	415v
Type of Material	Bulk materials, Pre-shredded materials, Recyclables
Weight	Up to 100 kg/m

Coveya Brochures Downloads

View All Downloads

Swan Neck Downloads Downloads

View All Downloads

What Support is Included?

At Coveya, we offer a range of support services for both hire and purchase customers. Below, you’ll find a simple breakdown of what each option includes, so you can choose the right level of support for your project.

Talk to an Expert

Service Type	Rental Support	Sales Support
Full Installation – We take care of on-site installation so you’re set up and ready
Maintenance Options – We can offer the right servicing and maintenance for you
Dedicated Service Team – Our dedicated service team is here to help with any conveyor issues when you need us
Scheduled Servicing – We’ll schedule on-site service visits every four weeks, and maintenance during downtime
Spare Parts – Extensive spare parts stock and unmatched lead times to keep you moving
